7″ Metal Cutting Disc
Metal Cutting Disc
A versatile 180 mm thin cutting disc for stainless steel and metal. The 1.6 mm profile balances responsive cutting with a more substantial wheel body, while the 7-inch diameter provides useful reach for pipe, profiles, sheet and general fabrication work.
180 mm
1.6 mm
Product Overview
A 180 × 1.6 × 22 mm thin cutting disc designed to balance cutting response, useful reach and everyday workshop versatility.
Its 1.6 mm profile is thinner than 2.5 mm and 3 mm alternatives for faster cutting response, while providing a more substantial wheel body than a specialist large-diameter 1 mm disc.
01
Balanced 1.6 mm Profile
The 1.6 mm wheel body supports responsive straight cutting while providing more wheel structure than an ultra-thin 1 mm large-diameter disc.
02
Useful 7-Inch Reach
The 180 mm diameter provides access across larger pipe sections, frames and fabricated components.
03
Fiberglass-Reinforced Structure
Fiberglass reinforcement supports the resin-bonded wheel structure during properly aligned straight-cutting operations.
04
Balanced Abrasive System
Selected aluminum oxide grains, functional fillers and an optimized resin bond support both responsive cutting and practical wheel life.
Applications
Typical 7-Inch Metal Cutting Applications
Suitable for fabrication, installation, repair and general workshop cutting with compatible equipment.
Pipe & Tube
Cutting stainless steel pipe, railing components and fabricated tube.
Profiles & Angle
Cutting mild-steel profiles, angle iron and light structural sections.
Sheet & Components
Straight cutting of sheet, covers and common workshop components.
Installation & Repair
General production, installation and maintenance cutting applications.
Technical Data
Technical Specifications
| Brand | KELIEF |
|---|---|
| Size | 180 × 1.6 × 22 mm |
| Outer Diameter | 180 mm (7″) |
| Thickness | 1.6 mm (1/16″) |
| Bore Size | 22 mm |
| Maximum Operating Speed | 80 m/s |
| Maximum RPM | 14,200 |
| Suitable Materials | Stainless Steel & Metal |
| Abrasive | Aluminum Oxide |
| Bond | Resin Bond |
| Reinforcement | Fiberglass Reinforcement |
| Manufacturing Process | Vacuum-Controlled Abrasive Mixing |
| Standard Packing | 200 pcs/carton |
| Customization | OEM / ODM |
Reach–Speed Balance
Speed, Reach & Everyday Versatility
The 180 × 1.6 mm format is positioned between ultra-thin and heavier large-diameter cutting discs, giving distributors a practical option for mixed workshop demand.
Faster Response
The 1.6 mm profile cuts with less wheel body than 2.5 mm and 3 mm alternatives.
More Reach
The 180 mm working diameter provides greater reach than 115 mm and 125 mm cutting discs.
Workshop Versatility
Suitable for mixed cutting demand across sheet, tube, profiles and small stock.
Distributor Range Fit
A practical mid-point between specialist ultra-thin and heavier-duty 180 mm cutting wheels.
OEM & Packaging
Private-Label Cutting Discs for Your Market
KELIEF supports OEM and ODM programs for importers, distributors, wholesalers and industrial suppliers. Standard packing for this model is 200 pieces per carton.
Need 180 × 1.6 × 22 mm Cutting Discs?
Send us your required quantity, destination market and packaging requirements for a KELIEF quotation and OEM proposal.
